Transformer-based 6kw Best Hybrid Solar 48V MPPT Single DC AC Onduleur on off Grid Inverters for Home

630 $

United States dollar ($) - USD

2 Items sold in last 3 minutes

18 People watching this product now!

Product Description

Specification

Model	YF-FS-WM 6348
DC Input Voltage	48V
Nominal Voltage	220VACStandard/110VACCustom
Frequency	50-60Hz Auto Sensing
5000WOutput Power	6400w
Output Voltage	220VAC±10%110VAC±10%
Waveform	Pure sine wave
Transfer TimeAC to DCDC to AC	<8ms
Bypass/Saver Mode	Yes
Efficiency	>98%
Input/output Protection	Circuit Breaker
Battery Type	AGM-Deep Cycle, Gel, LiFePO4Up to 500Ah
AC Charging Current	29A
Low Level Disconnect Selectable	40V Or 42V
Maximum PV Array Power	6400w
MPPT Input Voltage Range	MPPT: 60-150VDC
Maximum PV Array Open Circuit Voltage	MPPT: 150VDC
Maximum Solar Charging Current	120A
Temperature	-10-+50 °c
Humidity	C0-95%, Non condensing
Accoustic Noisedb	<45db
Package Sizemm	545400200
Net/Gross WeightKG	27.61/31.06
Battery Low Alarm	48V:battery light discharge46V;battery load discharge 46V@load<20%; 44V@load>50%/42V@load>50%;
Battery Low Recovery	48V:battery light discharge48V;battery load discharge 48V@load<20%;46V@load>50%/44V@load>50%;
DC Low Voltage Shutdown	48V:battery light discharge44V;battery load discharge 44V@load<20%;42V@load>50%/40V@load>50%;
DC High Voltage Alarm And Fault	64V
DC High Voltage Recovery	60V

Application

Hybrid Solar System

Output Power

6.2kw

Inverter Type

String Inverter

SKU: 1601300226390 Category: Solar & Backup Power

Description

Model	YF-FS-WM 6348
DC Input Voltage	48V
Nominal Voltage	220VACStandard/110VACCustom
Frequency	50-60Hz Auto Sensing
5000WOutput Power	6400w
Output Voltage	220VAC±10%110VAC±10%
Waveform	Pure sine wave
Transfer TimeAC to DCDC to AC	<8ms
Bypass/Saver Mode	Yes
Efficiency	>98%
Input/output Protection	Circuit Breaker
Battery Type	AGM-Deep Cycle, Gel, LiFePO4Up to 500Ah
AC Charging Current	29A
Low Level Disconnect Selectable	40V Or 42V
Maximum PV Array Power	6400w
MPPT Input Voltage Range	MPPT: 60-150VDC
Maximum PV Array Open Circuit Voltage	MPPT: 150VDC
Maximum Solar Charging Current	120A
Temperature	-10-+50 °c
Humidity	C0-95%, Non condensing
Accoustic Noisedb	<45db
Package Sizemm	545400200
Net/Gross WeightKG	27.61/31.06
Battery Low Alarm	48V:battery light discharge46V;battery load discharge 46V@load<20%; 44V@load>50%/42V@load>50%;
Battery Low Recovery	48V:battery light discharge48V;battery load discharge 48V@load<20%;46V@load>50%/44V@load>50%;
DC Low Voltage Shutdown	48V:battery light discharge44V;battery load discharge 44V@load<20%;42V@load>50%/40V@load>50%;
DC High Voltage Alarm And Fault	64V
DC High Voltage Recovery	60V
